Drill Head-QD-090-S1/A

Detailed description

Head Exchangeable Drill head--Self-locking

QD-S1/A

---Drill diameter 8-26 mm, available in 0.1mm increments

---Point angle: 140°

---Cutter bodies are available in 1.5xD,3xD,5xD,8xD and 12xD.

---Work on medium-high carbon steel, alloyed steel, stainless steel

---Micro-grain carbide grade, PVD-TIALN coating

• Designation	Dimensions(mm)		Drill Body
  	D	t
  QD-090-S1/A	9.0	5.8	QD090/099-12-D
  QD-091-S1/A	9.1	5.8
  QD-092-S1/A	9.2	5.8
  QD-093-S1/A	9.3	5.8
  QD-094-S1/A	9.4	5.8
  QD-095-S1/A	9.5	5.8
  QD-096-S1/A	9.6	5.8
  QD-097-S1/A	9.7	5.8
  QD-098-S1/A	9.8	5.8
  QD-099-S1/A	9.9	5.8
